| Code | VIBROLAB-5.К |
| Sensor type | Laser or inductive |
| Type of vibration sensors | Accelerometers, force sensors, with active and passive electronics |
| Dimensions (L x W x H) | 260 х 195 х 260 mm |
| Body design | Crate |
| User interface | External touch or regular display, keyboard and mouse – optional |
| Supported drive types | Servo drives or asynchronous variable frequency drives |
| The highest class of balancing accuracy according to ISO 1940-1:2003 | G 0,4 |
| Weight, no more than | 15 kg |
| Number of measured vibration displacement channels | 1 – 5 pcs. |
| Measurement range of vibration displacement amplitude | 0.01–1,000,000 µm (with a conversion factor of primary transducers from 1 to 1,000 mV/(ms-2) |
| Limits of the permissible relative error of the amplitude measurements | ±3 % |
| Range of permissible rotor rotational speeds | 90 - 30000 rpm |
| Limits of permissible rotor speed measuring error | ± (1+0.0025 n) rpm, where n is the number of rotor revolutions |
| Operating frequency range | 1,5 - 500 Hz |
| Type of angle sensor (encoder) | Built-in servo or external incremental |
| Consumed power, no more than | 250 W |
| Supply voltage | 1 phase, 230 V, 50 Hz, 6 A, protective earthing is mandatory |
| Operating temperature range | +10 - +35 °С |
| Average time to failure | 40000 h |
| Average service life | 25 years |
